We are a premier manufacturing enterprise renowned for our expertise in crafting top-tier air-slide fabrics, canvases, and a diverse array of industrial textiles. Leveraging extensive experience and technical prowess, we dedicate ourselves to delivering robust and dependable solutions tailored to the unique demands of various sectors.

Air slide fabrics, also known as airslide conveyor belts or aeration pads, are specialized materials used in pneumatic conveying systems. These systems are commonly employed in industries like cement manufacturing, food processing, and chemical processing, where bulk materials need to be transported in a powdered or granular form.

The air slide fabric is typically made of permeable, woven materials with a high tensile strength and a smooth surface. These fabrics allow air to pass through, creating an airflow that fluidizes and conveys the powdered or granular material.

The pneumatic conveying process involves using air pressure to move materials through a closed system, which can be more efficient and cost-effective than traditional mechanical conveying methods.

Air-slide Fabric

OPTIMIZING INDUSTRIAL AIR CONVEYANCE

Few reasons why choose us certainly.

1

Multifilament airslide fabrics are a type of air-permeable fabric used in pneumatic conveying systems to transport bulk materials in powdered or granular form. These fabrics are composed of multiple filaments, which are individual fibers twisted or grouped together. Multifilament polyester air slide has great performances of higher strength, service life and abrasion resistance.

MATERIAL: Multifilament

LENGTH: As per Customer Requirements

WIDTH: Up to 2000M

THICKNESS: 3mm to 12mm

TEMPERATURE RANGE: Continuous up to 180°C / Melting Point 270°C

MULTIFILAMENT AIRSLIDE FABRICS

2

Aramid fabrics are high-performance textiles made from aramid fibers, which are a class of synthetic fibers known for their exceptional strength, heat resistance, and flame-retardant properties. Aramid fibers are characterized by their long-chain, rigid polymer structure. Two of the most well-known aramid fibers are Kevlar and Nomex.

MATERIAL: Meta-Aramid, Para -Aramid

LENGTH: As per Customer Requirements

WIDTH: Up to 1800mm

THICKNESS: 2.5mm to 10mm

TEMPERATURE RANGE: Continuous up to 280°C / Melting Point 400°C

ARAMID AIRSLIDE FABRICS

3

Polyester airslide fabrics are a type of air-permeable fabric used in pneumatic conveying systems to transport bulk materials, particularly powdered or granular materials. These fabrics are constructed using polyester fibers, which are synthetic fibers known for their durability, resistance to abrasion, and chemical stability.

MATERIAL: Polyester

LENGTH: As per Customer Requirements

WIDTH: Up to 2000mm

THICKNESS: 3mm to 12mm

TEMPERATURE RANGE: Continuous up to 150°C / Melting Point 260°C

POLYESTER AIRSLIDE FABRICS

4

Cotton air-slide fabrics offer a unique combination of strength, flexibility, and breathability, making them ideal for various industrial applications. With their natural fiber composition, these fabrics provide excellent air permeability and moisture absorption properties, ensuring efficient pneumatic conveying of materials such as cement, flour, and other powdered substances.

MATERIAL: Cotton

LENGTH: As per Customer Requirements

WIDTH: As per Customer Requirements

THICKNESS: 4mm to 8mm

TEMPERATURE RANGE: Continuous up to 100°C / Melting Point 120°C

COTTON AIRSLIDE FABRICS
